Weight Indicators
Load cell indicators with best in class hardware for precise monitoring
Applications
Applications
PLC based Weighing Automation
Concrete Batching
Bag Filling
Bag Filling
Tank & Silo Weighing
Tank & Silo Weighing
Checkweighing
Checkweighing
Batch Weighing
Batch Weighing
Display
6 digit LED display
Max upto 6 (350 Ω; 5VDC)
Max upto 6 (350 Ω; 5VDC)
Loadcells
Loadcells
Power Supply
18-28VDC / 1 A
A/D Convertor
A/D Convertor
32-bit, ADC
32-bit, ADC
Conversion Rate
400 samples/sec
WI-400VP
WI-20
WI-10N
WI-10D
WI400 Models are High Speed Weight Indicator comes with digital input and output
WI-400VP-A-RS232
Weight indicators with Current, Digital output and Serial communication
0-20mA, 0-24mA, 4-20mA
Analog Output
1X RS232
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
WI-400VP-V-RS232
Weight indicators with Voltage, Digital output and Serial communication
0-10V, 0-5V, +/-5V, +/-10V
Analog Output
1X RS232
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
WI-400VP-A-RS485
Weight indicators with Current, Digital output and RS485 (Half Duplex) Communication
0-20mA, 0-24mA, 4-20mA
Analog Output
1X RS485
(Half Duplex)
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
WI-400VP-V-RS485
Weight indicators with Voltage, Digital output and RS485 (Half Duplex) Communication
0-10V, 0-5V, +/-5V, +/-10V
Analog Output
1X RS485
(Half Duplex)
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
WI-400VP
WI-20
WI-10N
WI-10D
WI400 Models are High Speed Weight Indicator comes with digital input and output
WI-400VP-A-RS232
Weight indicators with Current, Digital output and Serial communication
0-20mA, 0-24mA, 4-20mA
Analog Output
1X RS232
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
3X (5-24V DC)
Isolated High Logic
Digital Input
3X (24V DC / 1A)
Potential Free Contact
Digital Output
Height: 48 mm ,Width: 96mm,
Depth: 129 mm
Dimension
WI-400VP-V-RS232
Weight indicators with Voltage, Digital output and Serial communication
0-10V, 0-5V, +/-5V, +/-10V
Analog Output
1X RS232
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
3X (5-24V DC)
Isolated High Logic
Digital Input
3X (24V DC / 1A)
Potential Free Contact
Digital Output
Height: 48 mm, Width: 96mm,
Depth: 129 mm
Dimension
WI-400VP-A-RS485
Weight indicators with Current, Digital output and RS485 (Half Duplex) Communication
0-20mA, 0-24mA, 4-20mA
Analog Output
1X RS485
(Half Duplex)
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
3X (5-24V DC)
Isolated High Logic
Digital Input
3X (24V DC / 1A)
Potential Free Contact
Digital Output
Height: 48 mm ,Width: 96mm,
Depth: 129 mm
Dimension
WI-400VP-V-RS485
Weight indicators with Voltage, Digital output and RS485 (Half Duplex) Communication
0-10V, 0-5V, +/-5V, +/-10V
Analog Output
1X RS485
(Half Duplex)
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
3X (5-24V DC)
Isolated High Logic
Digital Input
3X (24V DC / 1A)
Potential Free Contact
Digital Output
Height: 48 mm ,Width: 96mm,
Depth: 129 mm
Dimension
WI-400VP
WI-20
WI-10N
WI-10D
WI400 Models are High Speed Weight Indicator comes with digital input and output
WI-400VP-A-RS232
Weight indicator with Current, Digital output and Serial communication
0-20mA, 0-24mA, 4-20mA
Analog Output
1X RS232
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
3X (5-24V DC)
Isolated High Logic
Digital Input
3X (24V DC / 1A)
Potential Free Contact
Digital Output
Height: 48 mm ,Width: 96mm, Depth: 129 mm
Dimension
WI-400VP-V-RS232
Weight indicator with Voltage, Digital output and Serial communication
0-10V, 0-5V, +/-5V, +/-10V
Analog Output
1X RS232
(Half Duplex)
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
3X (5-24V DC)
Isolated High Logic
Digital Input
3X (5-24V DC)
Isolated High Logic
Digital Output
Height: 48 mm , Width: 96mm, Depth: 129 mm
Dimension
WI-400VP-A-RS485
Weight indicator with Current, Digital output and RS485 (Half Duplex) Communication
0-20mA, 0-24mA, 4-20mA
Analog Output
1X RS485
(Half Duplex)
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
3X (5-24V DC) Isolated High Logic
Digital Input
3X (24V DC / 1A) Potential Free Contact
Digital Output
Height: 48 mm ,Width: 96mm, Depth: 129 mm
Dimension
WI-400VP-V-RS485
Weight indicator with Voltage, Digital output and RS485 (Half Duplex) Communication
0-10V, 0-5V, +/-5V, +/-10V
Analog Output
1X RS485
(Half Duplex)
Ports
DUMP, REQUEST, MODBUS-RTU, MODBUS-ASCII
Protocol
400 Per Sec
Conversion Rate
3X (5-24V DC)
Isolated High Logic
Digital Input
3X (24V DC / 1A)
Potential Free Contact
Digital Output
Height: 48 mm ,Width: 96mm, Depth: 129 mm
Dimension
